產品特色:

• 超快速 WiFi 7 (802.11be) 在 6 GHz 頻段和 4096-QAM 中具有新的 320MHz 通道，顯著提高了網路容量和吞吐量，速度高達 25 Gbps
• 多連結操作同時連結多個頻段，確保穩定的網路連線和高效率的資料傳輸
• 尖端的外部雙饋天線透過提供高效率和顯著增強的訊號強度來擴大覆蓋範圍
• 透過雙 10G 連接埠和四 2.5G 連接埠最大限度地提高有線連接和靈活性，為大多數頻寬密集型遊戲鋪平道路
• 免訂閱網路安全，採用由 Trend Micro™ 提供支援的商業級 AiProtection Pro，以及一鍵式安全掃描和安全瀏覽
• 全面的 VPN 功能，包括高級站點到站點 VPN 和 Instant Guard 行動應用程序，用於透過公共 WiFi 進行安全連接
• AiMesh 可擴展路由器具有豐富的高級功能，可實現整個家庭的無縫漫遊

產品規格:

Model Name:

GT-BE98

Network Standard:

• WiFi 6 (802.11ax)
• WiFi 7 (802.11be)
• IEEE 802.11a
• IEEE 802.11b
• IEEE 802.11g
• IEEE 802.11n
• IEEE 802.11ac
• IPv4
• IPv6

Product Segment:

BE25000 ultimate BE performance : 1376+5764+5764+11529 Mbps

WiFi Data Rate:

• 2.4GHz BE:

  4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps

• 5G-1Hz BE:

  4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps

• 5G-2Hz BE:

  4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps

• 6GHz BE:

  4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbps

Antenna:

External antenna x 8

Transmit / Receive:

• 2.4GHz 4x4
• 5GHz-1 4x4
• 5GHz-2 4x4
• 6GHz 4x4

Processor:

2.6GHz quad-core processor

Memory:

256 MB Flash and 2 GB RAM

Boosts Speed:

• OFDMA (Orthogonal Frequency Division Multiple Access)
• Beamforming: standard-based and universal
• 4096-QAM high data rate
• 20/40/80/160/320 MHz bandwidth

Operating Frequency:

2.4 GHz / 5 GHz / 6 GHz

Operating Mode:

Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge

I/O Ports:

• 1 x 10Gbps for WAN/LAN
• 1 x 2.5Gbps for WAN/LAN
• 1 x 10Gbps for LAN
• 3 x 2.5Gbps for LAN
• 1 x RJ45 10/100/1000Mbps for LAN
• 1 x USB 3.2 Gen1
• 1 x USB 2.0

Buttons:

WPS Button, Reset Button, Power Switch, LED control Button

LED Indicator:

• WAN(Internet) x1
• 10G LAN x1
• 1G/2.5G LAN x1
• 6GHz x1
• 5GHz-1 x 1
• 5GHz-2 x 1
• 2.4GHz x1
• Power x1

Power Supply:

• AC Input : 110V~240V(50~60Hz)
• DC Output : 19.5 V with max. 3.33 A current

Package Content:

• GT-BE98 quad-band gaming router
• RJ-45 cable
• Power adapter
• Quick Start Guide
• Warranty card

Product Weight (g):

2000 g

Product Dimensions:

350.41 x 350.41 x 220.6 mm

AiMesh:

• Primary AiMesh Router
• AiMesh Node

Game:

Game Boost / Acceleration, WTFast, ROG_First, OpenNAT (Game Profile), Gaming Port

Parental Control:

"Allow you to block access to unwanted websites and apps."

Parental Control Customized Internet Schedule:

64

Guest Network:

"The Guest Network provides Internet connection for guests but restricts access to your local network."

2.4 GHz + 5 GHz : 5

Guest Network Connection time limit:

Open system, WPA/WPA2/WPA3 Personal

Security:

• WPA/WPA2/WPA3 Personal
• WPA/WPA2/WPA3 Enterprise
• Open System & OWE
• WPS
• Let's Encrypt
• DNS-over-TLS
• SSH
• Security Scan
• Firewall

AiProtection:

• AiProtection Pro
• Router Security Assessment
• Malicious Site Blocking
• Two-Way IPS
• Infected Device Prevention and Blocking

VPN:

• Instant Guard
• VPN Client L2TP
• VPN Client Open VPN
• VPN Client PPTP
• VPN Client WireGuard
• VPN Server IPSec
• VPN Server Open VPN
• VPN Server PPTP
• VPN Server WireGuard
• VPN Fusion

Traffic Control:

• Adaptive QoS
• Bandwidth Monitor
• Bandwidth Limiter
• Traditional QoS
• Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
• Traffic Analyzer
• Daily, Weekly, Monthly
• Website History

WAN:

• Automatic IP, Static IP, PPPoE, PPTP, L2TP
• Dual WAN
• 3G / 4G LTE Dongle
• 4G / 5G Auto Mobile Tethering

Port Forwarding:

64

Port Triggering:

32

DMZ

DDNS:

PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay

LAN:

• DHCP Server
• IPTV
• LAN Link Aggregation
• Manually Assign IP Address
• Wake on LAN (WOL)

Wireless:

• MU-MIMO
• UTF-8 SSID
• WiFi MAC Address Filter
• Wireless Scheduler
• Airtime Fairness
• RADIUS Client
• Universal Beamforming
• Explicit Beamforming

USB application:

4G / 5G Auto Mobile Tethering, HFS+, NTFS, vFAT, ext2, ext3, ext4, Safely Remove Disk

AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server, Shared Folder Privileges

User Interface:

ASUSWRT

Administration

Configuration Backup and Restore, Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
